Pride Jazzy 1170XL Powerchair Electric Wheel chairs Heavy
Duty

Jazzy 1170 XL Features
Active-Trac suspension for outstanding outdoor performance
Adjustable front anti-tips to meet your preferences and terrain challenges
16" knobby drive wheels and optimum weight distribution provide superior traction
Speed range adjustable up to 6 m.p.h.
Jazzy 1170 XL Specifications
Drive Wheels 16" pneumatic
Rear Casters 9" Pneumatic Articulating
Anti-Tip Wheels Adjustable Front, 8" Solid
Suspension Full suspension with Active-Trac Suspension
Maximum Speed 6 MPH
Brakes "Intelligent Braking" electronic regenerative, disk park brake
Ground Clearance 4.25 inches
Turning Radius 22.5 inches
Overall Length 45 inches
Overall Width 26.5 inches
Medium Back Seat Contoured Medium Back (Standard)
Contoured Medium Back w/ Solid Seat pan (Optional)
Deluxe High Back Seat Contoured High Back (Optional)
Contoured High Back w/ Solid Seat pan (Optional)
Manual Recline Available
Versa Seat Adjustable Width: 13"-21"
Adjustable Depth: 10"-24"
Versa Tilt Seating System Adjustable Width: 16-22
Adjustable Depth: 14-22
Drive Train 2-motor mid-wheel drive
Battery Two 12-volt, group 24
Per-charge Range Up to 25 miles (varies with passenger weight)
Battery Charger Onboard (standard)
Battery Weight 48 lbs. (each)
Battery Well Weight N/A
Electronics P&G Pilot 70-amp controller (standard)
P&G Remote Plus 70-amp controller
Dynamic Europa 70-amp remote controller
Weight Capacity 400 lbs.
Base Weight 124.5 lbs.
Seat Weight 29 lbs.
Colors Standard: Champagne and Gray
Optional: Candy Apple Red, Viper Blue, Forest Green, Caribbean Teal, Purple Pizazz and Black Onyx
Curb Climbing Height 6"
Warranty: |
Lifetime Limited Warranty
For the lifetime of your Jazzy, from the date of purchase, Pride
Mobility Products Corporation
Two-Year Warranty
For two (2) years from the date of purchase of your Jazzy, Pride
Mobility Products Corporation
Eighteen-Month Warranty
For eighteen (18) months from the date of purchase of your Jazzy,
Pride Mobility Products
Six-Month Limited Warranty
For six (6) months from the date of purchase, Pride Mobility Products
Corporation will repair
|
