Available
in 2 - 8 foot lengths This ultra-strong, single-fold ramp provides the safety and strength required while remaining lightweight and portable. The smooth and quiet action of the living hinge, a continuous full length low profile hinge, adds strength and stability to the ramp. Features an extruded non-skid tread for superior traction, and a self-adjusting bottom transition plate for easy conversion from ramp to ground. Welded construction provides long-term durability and safety. |
Features: |
|
![]() |
|
|
Ergonomically designed
flexible, non-breakable handles offer convenient
carrying and a comfortable grip. |
The hinge features a no-pinch,
non-protruding live hinge for safe, silent, and maintenance free operation. |
Options: |
|
|
|
Optional Top Lip Extension (TLE) will increase the reach of the SUITCASE Signature Series ramp by extending the lip from the standard 3" length to 9". The EZ-ACCESS TLE is unique because it can be added or removed as needed, eliminating the need for a large ramp inventory. Shipped as a pair. |
|
SPECIFICATIONS
|
SUITCASE
SS2 |
SUITCASE
SS3 |
SUITCASE
SS4 |
SUITCASE
SS5 |
SUITCASE
SS6 |
SUITCASE
SS7 |
SUITCASE
SS8 |
| Made of aluminum |
|
|
|
|
|
|
|
| Non-skid surface |
|
|
|
|
|
|
|
| Built-in carrying handle |
|
|
|
|
|
|
|
| Usable size |
2x30"
|
3'x30"
|
4'x30"
|
5'x30"
|
6'x30"
|
7'x30"
|
8'x30"
|
|
Folded size (L x W x H) |
24"x15"x4"
|
36"x15"x4"
|
42"x15"x4"
|
48"x15"x4"
|
60"x15"x4"
|
74"x15"x4"
|
86"x15"x4"
|
| Weight (lbs.)* |
11
|
17
|
23
|
29
|
34
|
41
|
47
|
| Weight capacity (lbs.) |
800
|
800
|
800
|
800
|
800
|
800
|
800
|
| For wheelchairs & scooters |
|
|
|
|
|
|
|
| Usage guidelines** | Curbs, 1 step |
Curbs, 1 step |
Curbs, 1-2 steps |
Curbs, 1-2 steps, some minivans |
1-3 steps,
some minivans & SUVs |
1-3 steps,
some minivans & SUVs |
2-3 steps,
some minivans & SUVs |
*Weights are approximate and may vary.
** Consult your equipment's owner guide for proper
degree of incline. Never exceed its recommendations.
|
||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
![]() |
||||||||||||||||||
| The rubber CARGO
WEDGE is the ideal solution when recessed cargo
areas leave you in a rut. Without altering the
vehicle, the CARGO WEDGE compensates for the
difference between the rear door threshold and
the lower-level cargo area, allowing mobility
equipment to be loaded/unloaded with a smooth
transition.
The CARGO WEDGE, when used in conjunction with the SUITCASE® or TRIFOLD Advantage Series® Ramp, or SUITCASE® Signature Series® Ramp, provides the perfect transport system for mobility access. Slip-resistant and made of 100% recycled tires.
|
||||||||||||||||||
*Weights are approximate and may vary.
|
||||||||||||||||||
|
|
Available in 1, 1.5, 2, 3, 4, 5, & 6 inch heights The EZ-ACCESS Threshold ramp is a lightweight yet durable free-standing modular ramp designed for doorways, sliding glass doors, and raised landings. This seam-free ramp is 34" wide and easily accommodates thresholds from ¾" to 6" high. Ideal for use with wheelchairs, walkers, and cane users. Made of anodized aluminum and is intended for indoor or outdoor use. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||












TLE Specifications
